Features and uses
Features
- Manual on/off and dimming for line voltage lights
- Adjustable minimum brightness
- Integrates with other smart devices in the Redwoods Connect App
- Trailing Edge dimming which is more suitable than leading edge dimming for LED lights
Use cases
- Power outdoor lights on/off at the same time as the landscape lighting, such as porch lights or lights outside the garage
- Connect to an inside light and use an Automation to power on/off and dim a light at a set schedule
Technical specs
- Working Voltage 100V-240V AC
- Wattage LED and CFL 150W | Incandescent 400W
- Frequency 2.4Ghz WiFi only, not compatible with 5Ghz WiFi
- Dimming Trailing edge dimming, ideal for LED's
- Weather Protection Indoor rated. Not for outside use.
- Requirements 2.4Ghz WiFi | Neutral wire | Single pole
Preparation
What you'll need
- WiFi dimming wall switch
- Voltage detector
- 4 pcs wire nuts
- Electrical tape
- Device with Redwoods Connect app installed and on 2.4Ghz WiFi network
